Vacon NX Service Manual

Fault codes and software
24h on-call service phone: +358 (0)40 83 71 150
24
4
10. 3. 1. 2. NXL00005V247
• Processor changed. Older software does not work on boards listed in table
below.This software supports both processor versions. M30624FGAGP is used today
and will be replaced by M30624FGPGP#D5 (or #U5 lead free).
10. 3. 1. 3. NXL00005V248
• Corrected reading of active fault with subcode.
• Corrected bug in fault history order.
• MF6 Fan control added (new VB00558.A).
• BackNet optioncard definition fixed.
10. 3. 1. 4. NXL00005V242
Equal to NXL00005V142, except for new loader inside VCN-file, which supports both
NXL processor versions. This version to be used if customer is requiring old system
software version. See service bulletin SBU00024 0524 for more information.
10. 3. 1. 5. NXL00005V249
Changes to temperature measurement.
10. 3. 1. 6. NXL00005V250
See additional info from NXL Product annoncement dated 13.3.2006
• SW-support for two option board slots (MF4-6)
• Start-up Wizard
• Some other new software features such as motor identification and RO delay
parameters added)
TABLE 8. Compatible boards with NXL00005V247 or newer software.
Boards
VB00351K
VB00352N
VB00353N
VB00354H
VB00355I
