Vacon NX Service Manual

Fault codes and software
email: service@vacon.com Tel: +358 (0)201 212 575 Fax: +358 (0)204 335 091
25
4
• Support for New option board, OPT-AI
10. 3. 1. 7. NXL00005V251
Fixed problem with loader in NXL-software. Old NXL loader software (v.49.1) will not always
erase new controller M30624FGPGP flash. Loader updated to v.49.2.
10. 3. 1. 8. NXL00005V252
Used in production since 05.09.2006.
Changes (Firmware):
• Default fsw of MF2-3 changed to 2.6kHz
• Motor over temperature protection improved
• Start-up Wizard improved
Changes (Application):
• New alternative for PID actual value P2.9.3:7 = Al1-Al2
• Start-up Wizard improved
• Prohibit freguency group 2.5 made visible
• Improvement of “4mA reference fault” supervision
10. 3. 1. 9. NXL00005V253
Replaced version: NXL00005V252.
Used in production since 19.09.2006.
Changes (Application):
• Start-up Wizard improved (default current limits of modes Std and HP changed)
10. 3. 1. 10. NXL00005V254
Used in production since 27.04.2007.
TABLE 9. Compatible boards with NXL00005V250 or newer software.
Boards
VB00351K
VB00352N
VB00353N
VB00354H
VB00355I
VB00558A

Vacon NX Specifications

General

Product Type	AC Drive
Control Method	Scalar Control
Enclosure	IP00, IP21
Communication	Ethernet
Safety	STO (Safe Torque Off)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Ambient Temperature Range	-10°C to +50°C (with derating above +40°C)
Cooling Method	Air-cooled, Liquid-cooled
