Vacon NX Service Manual

Fault codes and software
email: service@vacon.com Tel: +358 (0)201 212 575 Fax: +358 (0)204 335 091
27
4
• Default value for DCBrakeCurrent parameter is based on the unit size. Previously
the default value was always 1.00A
10. 3. 1. 14. NXL00005V258
Used in production since 22.02.2008.
Changes (Application):
• Monitoring of motor calculated temperature moved to V1.26 (from V1.10)
• Parameter file downloading improved (stop function, P2.1.12, was not copied,
always coasting)
10. 3. 1. 15. NXL00005V259
Used in production since 07.05.2008.
Changes (Firmware):
• Changes to the fan speed control of MF6 drives
TABLE 10. Compatible boards with NXL.
Boards Voltage
VB00351L Control board
VB00350L MF4 500V
VB00357G MF5 500V
VB00558F MF6 500V
VB00352P MF2 400V
VB00353P MF3 400V
VB00354K MF2 200V
VB00355K MF3 200V
TABLE 11. Control boards used software version NXL00005V247 or later.
Control boards
VB00352N
VB00354H
VB00353N
VB00355i
VB00351K

Vacon NX Specifications

General

Product Type	AC Drive
Control Method	Scalar Control
Enclosure	IP00, IP21
Communication	Ethernet
Safety	STO (Safe Torque Off)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Ambient Temperature Range	-10°C to +50°C (with derating above +40°C)
Cooling Method	Air-cooled, Liquid-cooled
