VADDIO RoboSHOT 30 - Command Setting Values; Exposure Control

RoboSHOT HD Cameras
RoboSHOT HD Cameras - Document Number 342-0796 Rev C Page 48 of 68
COMMAND SETTING VALUES
Exposure Control
Shutter
Speed
Value 60/59.94/30/29.97 50/25
0x15 1/10000 1/10000
0x14 1/6000 1/6000
0x13 1/4000 1/3500
0x12 1/3000 1/2500
0x11 1/2000 1/1750
0x10 1/1500 1/1250
0x0F 1/1000 1/1000
0x0E 1/725 1/600
0x0D 1/500 1/425
0x0C 1/350 1/300
0x0B 1/250 1/215
0x0A 1/180 1/150
0x09 1/125 1/120
0x08 1/100 1/100
0x07 1/90 1/75
0x06 1/60 1/50
0x05 1/30 1/25
0x04 1/15 1/12
0x03 1/8 1/6
0x02 1/4 1/3
0x01 1/2 1/2
0x00 1/1 1/1
Iris Value RoboSHOT
12
RoboSHOT
30
0x11 F1.8 F1.6
0x10 F2 F2
0x0F F2.4 F2.4
0x0E F2.8 F2.8
0x0D F3.3 F3.4
0x0C F4 F4
0x0B F4.8 F4.8
0x0A F5.6 F5.6
0x09 F6.8 F6.8
0x08 F8 F8
0x07 F9.6 F9.6
0x06 N/A F11
0x05 N/A F14
0x00 CLOSE CLOSE
Iris
Gain
Value Steps
0x0F 28
0x0E 26
0x0D 24
0x0C 22
0x0B 20
0x0A 18
0x09 16
0x08 14
0x07 12
0x06 10
0x05 8
0x04 6
0x03 4
0x02 2
0x01 0
Iris
Gain
Limit
Value Steps
0x0F 28
0x0E 26
0x0D 24
0x0C 22
0x0B 20
0x0A 18
0x09 16
0x08 14
0x07 12
0x06 10
0x05 8
0x04 6
Exposure
Comp.
Value Iris Gain
0x0E +7 +10.5 dB
0x0D +6 +9 dB
0x0C +5 +7.5 dB
0x0B +4 +6 dB
0x0A +3 +4.5 dB
0x09 +2 +3 dB
0x08 +1 +1.5 dB
0x07 0 0 dB
0x06 -1 -1.5 dB
0x05 -2 -3 dB
0x04 -3 -4.5 dB
0x03 -4 -6 dB
0x02 -5 -7.5 dB
0x01 -6 -9 dB
0x00 -7 -10.5 dB
