REM Contact Quality Monitor
Technical Specifications
Force 2 Service Manual 4-5
REM Contact Quality Monitor
If impedance measured is outside the acceptance range, a REM alarm will
occur. In the REM mode, if resistance increases by more than 40% above
the reference value, or above 135 ohms, an alarm will be generated.
Audio Volume
The mode indicator tones are adjustable from 45 to > 65 dBA at 1 meter.
The alarm tones are set to a level of > 65 dBA at 1 meter and are not
adjustable.
Approximate Weight
10 kg (22 lbs)
Size
20 x 33 x 53 cm (8 x 13 x 21 in.)
Classification
Type CF Equipment per IEC 601-1
The Force 2 generator provides a high degree of protection against
electrical shock, particularly regarding allowable leakage current and has
a CF type isolated (floating) applied part. The applied part may be used
on the heart. Defibrillator protected.
Drip Proof per IEC 601-1
The Force 2 generator enclosure will prevent reasonable amounts of
falling liquid from interfering with the generator’s safe and satisfactory
operation.
All monopolar output measurements are made using the setup referred to
in IEC 601-2-2, Figure 104.
Measurement Frequency
140 kHz ± 20 kHz
Measurement Current
3.0 mA, maximum
Acceptable Resistance
Ranges
Single area pad - nominally < 24 ohms
Dual area REM - nominal range 5 - 135 ohms
