Valleylab Force 2-2 PCH - Table of Contents

Force 2 Service Manual v
Table of Contents
Conventions Used in this Guide
iii
Valleylab Service Centers
iv
List of Figures
viii
Section 1. Service Warnings and Cautions
Section 2. Unpacking and Installation
Unpacking the Force 2 Generator
2-1
Responsibility of the Manufacturer
2-1
Preparing the Generator for Use 2-2
Power Requirements
2-2
Check the Power Connector
2-2
Ensure Proper Grounding
2-3
Perform a System Check
2-3
Section 3. Description of Controls, Indicators, and Receptacles
Controls
3-3
Indicators
3-4
Alarms 3-5
Receptacles
3-5
Rear Panel Functions
3-6
Section 4. Technical Specifications
Standard Conditions of Measurement
4-1
Operating Parameters
4-1
Storage and Shipping
4-1
Output Waveform
4-2
PCH Generator Output Characteristics
4-2
Output Configuration 4-2
Input Power Source
4-3
Force 2-2 PCH Generator
4-3
Force 2-8 PCH Generator
4-3
Line Regulation
4-3
Force 2-2 PCH Generator
4-3
Force 2-8 PCH Generator
4-3
High Frequency Risk Parameters
4-4
