Valleylab Force 2-2 PCH - Heatsink Assembly

Heatsink Assembly
Service Parts List
Force 2 Service Manual 8-13
Heatsink Assembly
RF Out
HVDC
PS
Clamp
Reference Designator Description
Valleylab
Part Number
Q1-4 Transistor FET BUZ80A 239 200 020
R6 500 Ω, 500W TO-220 234 400 271
Reference Designator Description
Valleylab
Part Number
CR21-24 MUR 8100E 239 850 033
R142 150 Ω, 20W TO-220 234 400 251
Reference Designator Description
Valleylab
Part Number
CR25-28 FET N-Channel 500V 8A 239 200 022
R133 50 Ω, 20W TO-220
Bridge 400V 35A
234 400 272
239 700 067
Reference Designator Description
Valleylab
Part Number
Q5 FET N-Channel 500V 8A 239 200 022
Q6-9 Transistor FET BUZ80A
Resistor Assembly F2-PCH
239 200 020
207 500 198
202 701 789
202 701 790
202 701 791
202 701 792
