Valleylab Force 2-2 PCH - Monopolar Control;Display Board

Monopolar Control/Display Board
8-2 Force 2 Service Manual
Monopolar Control/Display Board
201 496 000
Reference Designator Description
Valleylab
Part Number
Resistors
R24, 27, 39, 44 10k Ω ± 5%, 1/4W 234 024 087
R2, 8, 22 100k Ω ± 5%, 1/4W 234 024 111
R5, 21, 31, 34 1k Ω ± 5%, 1/4W 234 024 063
R7 51 Ω ± 5%, 1W 234 204 112
R9, 46, 48 330 Ω ± 5%, 1/4W 234 024 051
R1, 3, 4, 6, 10, 13, 14, 25, 26, 45, 47 3.3k Ω ± 5%, 1/4W 234 024 075
R11 750 Ω ± 5%, 1/4W 234 024 060
R12 1.6k Ω ± 5%, 1/4W 234 024 068
R14 33k Ω ± 5%, 1/4W 234 024 099
R15-18 75 Ω ± 5%, 1/2W 234 014 086
R19 100 Ω ± 5%, 1/4W 234 024 039
R23 130k Ω ± 5%, 1/4W 234 024 114
R20, 29, 49 4.7k Ω ± 5%, 1/4W 234 024 079
R32, 33, 37, 41 51 Ω ± 5%, 1/2W 234 014 083
R35, 43 1.8M Ω ± 5%, 1/4W 234 024 141
R36 10k Ω ± 10%, 5W Trimpot 236 200 091
R40 24k Ω ± 5%, 1/4W 234 024 096
R42 20k Ω ± 5%, 1/4W 234 024 094
RA1-4 10k Ω resistor array 234 100 171
Capacitors
C1, 3 10 µF ± 20%, 25V 204 600 067
C5, 6, 10, 12, 13, 15, 18, 19, 21-24, 27,
28, 30-33, 35, 36,40, 45, 46, 48-51
0.1 µF ± 20%, 50V 204 200 460
C4, 8, 17, 29, 42 1 µF ± 20%, 50V 204 200 464
C2, 16, 25 1000 pF ± 10%, 100V 204 200 454
C9 22 pF ± 5%, 100V 204 200 450
C14, 41 33 pF ± 5%, 100V 204 200 451
