Valleylab Force 2-2 PCH - Power Supply RF Board

Power Supply RF Board
8-8 Force 2 Service Manual
Power Supply RF Board
K1, 2 Reed Relay, 10kV 230 007 007
K3 Double Pole Relay 230 012 000
Reference Designator Description
Valleylab
Part Number
(-8 PCH) 202 701 918
(-2 PCH) 202 701 917
Reference Designator Description
Valleylab
Part Number
Resistors
R12 47k Ω ± 5%, 1/2W 234 014 115
R42 82k Ω ± 5%, 1/2W 234 014 120
R43 120k Ω ± 5%, 1/2W 234 014 124
R16 3.9 Ω ± 5%, 1/4W 234 024 005
R86 10 Ω ± 5%, 1/4W 234 024 015
R1, 2, 4, 5, 7-11, 125 22 Ω ± 5%, 1/4W 234 024 023
R120 36 Ω ± 5%, 1/4W 234 024 028
R109, 110 10 Ω ± 5%, 1/2W 234 014 068
R134, 138, 139, 141 51 Ω ± 5%, 1/4W 234 024 032
R81 360 Ω ± 5%, 1/4W 234 024 052
R118 560 Ω ± 5%, 1/4W 234 024 057
R20, 23, 27, 30, 32, 41, 46, 48, 49, 79,
96, 108, 114, 127, 135-137, 140
1k Ω ± 5%, 1/4W 234 024 063
R26, R83, R126 1.5k Ω ± 5%, 1/4W 234 024 067
R21 1.8k Ω ± 5%, 1/4W 234 024 069
R3, 22*, 95, 107 2k Ω ± 5%, 1/4W 234 024 070
R17, 29, 60, 80, 84, 100 2.7k ± Ω 5%, 1/4W 234 024 073
*For -2 PCH only, change R22 to 1 kΩ ± 5% 1/4W 234 024 063
