Valleylab Force 2-2 PCH - Page 65

Interface Board
Service Parts List
Force 2 Service Manual 8-7
C22, 44 0.01 µF ± 10%, 100V 204 600 457
C15 10 µF ± 10%, 20V 204 600 064
Integrated Circuits
U6, 7, 9, 10 4049B 210 210 049
U1, 8 LM339AN 210 300 015
U3 4013B 210 027 001
U2 79LO5AC 210 300 071
U4 4011B 210 210 011
U11 4066 210 200 022
U5 LM358AN 210 300 013
Transistors
Q6, 7 VN10KM 239 200 012
Q1, 3-5 2N3904 239 015 000
Q2 2N2907A 239 100 012
Diodes
CR1, 3-5, 8-11, 13-15 1N4148 239 014 000
CR2, 6, 7, 16 1N5240B 239 600 001
CR12 1N5233B 239 600 000
Optoisolators
OPT1-6 OPI1264C 239 750 019
OPT7-9 4N35 239 750 002
Miscellaneous
T3 Transformer, RF Input 251 200 078
T1, 2 IsoBloc Toroid 251 300 019
Reference Designator Description
Valleylab
Part Number
