Interface Board
8-6 Force 2 Service Manual
R15 5k Ω trimpot 236 010 006
R44 68k Ω ± 5%, 1/4W 234 024 107
R23 560k Ω ± 5%, 1/4W 234 024 129
R16 100k Ω trimpot 236 010 011
R24 910k Ω ± 5%, 1/4W 234 024 134
R17 200k Ω ± 5%, 1/4W 234 024 118
R25 160k Ω ± 5%, 1/4W 234 024 116
R47 10.2k Ω ± 1%, 1/8W 234 201 386
R67 390k Ω ± 5%, 1/4W 234 024 125
R27, 36 200k Ω ± 1%, 1/8W 234 201 510
R46, 66 887 Ω ± 1%, 1/8W 234 201 284
R69 19.1k Ω ± 1%, 1/8W 234 201 412
R70 33k Ω ± 5%, 1/4W 234 024 099
Capacitors
C58, 61 0.22 µF ± 10%, 250V 204 400 120
C16, 17, 59 0.0047 µF ± 20%, 10kV 204 200 243
C60 0.0047 µF ± 20%, 6kV 204 025 050
C2-5, 10, 11, 18, 19, 21, 23, 24, 31-33,
36, 38, 41, 43, 48-53, 56, 64, 69
0.1 µF ± 20%, 50V 204 200 460
C1, 6-9, 12-14, 20, 25-29, 37, 39, 40, 42,
47, 54, 57, 65, 68
1 µF ± 20%, 50V 204 200 464
C34, 55 240 pF ± 5%, 500V 204 300 331
C62, 66, 67 1000 pF ± 10%, 100V 204 200 454
C63, 71 3300 pF ± 10%, 100V 204 200 455
C30, 35, 70 10 µF ± 20%, 25V 204 600 067
Reference Designator Description
Valleylab
Part Number
