Power Supply RF Board
8-12 Force 2 Service Manual
CR6 1N5817 239 700 005
CR7, 8, 10, 11, 13, 15-20, 25-28 1N4148 239 014 000
CR9 1N5233B 239 600 000
CR12 LM336-5 210 300 018
CR14 LM336-2.5 210 300 016
Miscellaneous
F1 (Force 2-2 PCH) Fuse 6A, 250V 215 005 039
F1 (Force 2-8 PCH) Fuse 6.3A, 250V 215 100 041
K1 4 pole relay 230 007 002
RT1 Thermistor 5 Ω, 6A 240 003 005
L2 Inductor 0.75 mH 251 100 107
L1 Cut Inductor 251 100 108
T1 Output Transformer 251 200 060
T2 Switching Transformer 251 200 061
T3 Dual Pulse Transformer 251 300 014
Reference Designator Description
Valleylab
Part Number
