Typical Output Waveforms
Maintenance Procedures
Force 2 Service Manual 6-11
Figure 6-3.
Blend 2 300 Ω Load
Figure 6-4.
Blend 3 300 Ω Load
Low Voltage Coag 300 Ω Load
