Valleylab Force 2-2 PCH - Page 68

Power Supply RF Board
8-10 Force 2 Service Manual
R69-76 10k Ω trimpot 236 200 079
R61-63 20k Ω trimpot 236 200 080
R101 50k Ω trimpot 236 200 082
R89 20k Ω ± 5%, 1/4W 234 024 094
J11, 13 0 Ω jumper 234 300 080
J6 (Force 2-2 PCH only) 0 Ω jumper 234 300 080
J7 (Force 2-8 PCH only) 0 Ω jumper 234 300 080
Capacitors
C13, 34 100 pF ± 5%, 100V 204 200 452
C2, 4, 9, 11, 15, 18, 19, 21, 23-25, 27,
28, 35, 36, 39-43, 45, 47, 50, 51, 58, 61,
66-71, 77, 80, 82-84
.1 µF ± 20%, 50V 204 200 460
C7, 16, 17, 37, 38, 44, 52, 53, 55-57,
62, 65
1 µF ± 20%, 50V 204 200 464
C54, 59 .033 µF ± 10%, 100V 204 200 503
C60 47 pF ± 5%, 100V 204 200 533
C1, 3, 8, 10 22 µF ± 20%, 25V 204 600 063
C20, 26, 32, 33, 81 10 µF ± 20%, 25V 204 600 067
C14 .01 µF ± 10%, 100V 204 200 457
C64 .0022 µF ± 20%, 6KV 204 025 044
C74 1500 pF ± 5%, 500V 204 300 350
C49 2200 pF ± 5%, 500V 204 300 354
C29 470 pF ± 5%, 500V 204 106 027
C22 12000 pF ± 5%, 500V 204 300 130
C6 15000 pF ± 5%, 500V 204 300 132
C76 1200 pF ± 5%, 500V 204 300 348
Reference Designator Description
Valleylab
Part Number
