3.9.2 The minimum allowable distance from the outside of the appliance fascia to a
corner wall having combustible material or any other combustible surface which
projects beyond the front of the appliance is shown in figure 4.
A 10mm access clearance from a non-combustible surface is necessary at the left
side (See figure 4).
INSTALLER GUIDE
Figure 4. Appliance dimensions and clearances (Continued on next page)
