Valor Fires 940 - Installation Options; Conventional Fireplace and Hearth

Page 14
© Baxi Heating U.K. Limited 2009.
3.10 Installation options.
In the United Kingdom, as supplied, the appliance can be installed in the following
situations: -
3.10.1 Conventional fireplace and hearth.
To a fireplace complete with surround and hearth as shown in figure 5 and complying
with BS1251 after removal of the fireback and sufficient material behind the fireback
for a debris catchment space. The required fireplace and debris catchment area are
shown in figure 6.
INSTALLER GUIDE
Figure 4 continued. Appliance dimensions and clearances
Key Description
Model
Adorn Visage Icon Dream Eternal Decadent Obsession
A Height (mm) 768 611 622 636 611 625 621
B Width (mm) 545 529 631 518 514 529 530
C
Depth into room
(mm)
88 94 64 94 76 92 96
D
Minimum
mandatory
clearance to
combustible
surfaces
projecting
beyond the front
of appliance
(mm).
100 108 65 100 100 108 100
E
Recommended
clearance to
non-
combustible
surfaces for
access purposes
(mm).
10 10 65 50 50 108 50
