4. PACK CONTENTS
Carefully remove all the contents. Take special care in handling the ceramic pieces.
Take care not to bend or distort the slide control linkage when handling the fascia.
Check that all the listed parts are present and in good condition.
The items required for this appliance are packed in sections.
Section 1 - Fire unit contains:
Page 19
© Baxi Heating U.K. Limited 2009.
INSTALLER GUIDE
1 Burner and convection box unit (On Dream models a slider control is fitted to the
convector box).
1 Inlet ‘T’ connector including pressure test point, nut and olive for 8mm inlet pipe.
2 Small “U” seals (For convection box side flanges).
1 Strip of floor sealing tape.
6 Fibre plugs (Four for eyebolts / screws and two for floor fixing).
4 Woodscrews.
2 Fire retaining cables.
2 Cable clamps.
4 Eyebolts.
1 Rubber grommet.
1 Flue restrictor.
1 Rear ceramic wall support bracket.
2 No.8 x 3/8” Screws (For rear ceramic wall support bracket).
3 No.8 x 3/8” Screws (For flue restrictor).
3 No.8 x 3/8” Screws (For outlet baffle / heatshield).
4 No.8 x 3/8” Screws (For fitting the hood on the Dream).
1 Knurled shouldered screw (For control linkage fixing).
2 M4 x 30mm machine screws (For Adorn fascia securing).
2 M4 x 25mm machine screws (For Dream fascia securing).
2 M4 x 10mm screws (zinc) (For Decadent fascia securing).
2 M4 x 10mm screws (black) (For Decadent, Obsession, Eternal and Visage fascia
bracket securing).
2 Washers (For Adorn and Dream fascia securing)
2 Surround securing brackets on Visage, Eternal and Decadent.
1 Slider control label.
1 PP3 Battery.
1 Smoke match tube.
1 Length of self adhesive foam seal.
1 Literature pack.
1 Ceramic fuel effect pack including a fuel effect (Not shown), a ceramic back wall
and a pair of ceramic side walls.
