Page 22
© Baxi Heating U.K. Limited 2009.
INSTALLER GUIDE
Section 2 - Dream fascia pack contains:
1 Fascia.
1 Bottom front cover casting
In accessory pack
1 Outlet baffle.
1 Burner tray baffle.
1 Control position label.
1 Hood
Section 2 - Adorn fascia pack contains:
1 Fascia with sliding control.
1 Bottom front cover casting.
1 Outlet baffle.
Section 2 - Icon fascia pack contains:
1 Fascia with sliding control.
1 Bottom front cover.
1 Top heat shield.
2 Knurled screws for bottom front
cover fixing.
2 Cross over port covers.
Figure 9. Pack contents continued
