OWNER GUIDE
Figure 3 continued. Appliance dimensions and clearances.
Key Description
Model
Adorn Visage Icon Dream Eternal Decadent Obsession
A Height (mm) 768 611 622 636 611 625 621
B Width (mm) 545 529 631 518 514 529 530
C
Depth into room
(mm)
88 94 64 94 76 92 96
D
Minimum
mandatory
clearance to
combustible
surfaces
projecting
beyond the front
of appliance
(mm).
100 108 65 100 100 108 100
E
Recommended
clearance to
non-
combustible
surfaces for
access purposes
(mm).
10 10 65 50 50 108 50
