VARI❋LITE® - VL2402™ WASH LUMINAIRE USER’S MANUAL
64 17-Sept-01 02.9671.0001 C
P/T Pan/Tilt Accesses pan and tilt options for DMX function, system configuration, and
testing.
Pan Pan Specifies pan function for manual control (Man) or pan encoder for testing (Test).
PASS Test Pass Indicates that sensor test has passed.
PCue Play Cue Accesses cue list for play back of cues by number.
POWR Lamp Power Accesses function to turn lamp on or off.
PROG Programming Currently programming the new version of software.
PSEQ Play Sequence Plays back cue sequence. Press [Enter] to start and [Menu] to stop.
RCAL Recalibrate Currently executing Calibration.
RDef Reset Default Resets default system configuration values.
RHrs Reset Lamp Info Resets lamp hour and lamp strike counters. For use when new lamp is installed.
RTST Run-Test Indicates that a system mechanism test is in progress.
SAVE Save Saving cue data.
ScXX Sequence Data Sequence playing cue number, where XX defines cue number.
Sens Sensors Accesses sensor choices for diagnostic testing.
SEQ Sequence Playback Sets sequence playback mode to Individual (plays cues from each luminaire) or
Master (all luminaires play same cue).
SNAP Snap Enables, disables the colors (Blue, Amber, or Magenta) taking the shortest
distance from one color to the next.
STAT Status/Error Display Allows scrolling through error list or displays OK if no errors.
Stor Store Cue Stores cue by number. Cue number stored is dependent on next cue ID in cue
list since this field is not editable.
Strb Strobe Specifies strobe function for manual control.
Strk Strike Displays total number of lamp strikes.
STST Sensor Test Indicates that a system sensor test is in progress.
SWAP Swap Swaps pan and tilt functions for special focus requirements such as moving
mirror mechanisms.
Test System Tests Accesses diagnostic tests for internal mechanisms.
Tilt Tilt Specifies tilt function for manual control (Man) or tilt encoder for testing (Test).
Time Timing Data Allows manual setting of timing values for dimmer/intensity, focus, color, and
beam.
Ver Version Displays current software version (in two pages).
VIRT Virtuoso console Sets starting address for luminaire in Virtuoso systems.
Table 4-3: Menu Function Definitions (Continued)
Display Definition Purpose
