FAN 2 RELATIVE SET POINT
The Fan 2 relative set point establishes the
temperature above the main set point at which
Fan 2 begins to operate at its minimum speed.
The value is a temperature
difference
from
the main set point.
The Fan 2 relative set point is adjusted in 0.5
degree increments from a minimum setting of
0.0°C (0.0°F) to a maximum setting of 10.0°C
(18.0°F).
Adjusting the relative set point of Fan 2:
•rotate the selector dial to position (5),
•rotate the adjuster dial counterclockwise to
decrease the relative set point, clockwise to
increase it.
The Fan 2 relative set point is displayed on the
ECS.
5
CHAPTER 3 - USER’S GUIDE
Example: A main set point of 22°C along
with a Fan 2 relative set point of 5°C is
selected. When room temperature reaches
27°C Fan 2 begins to operate at minimum
speed.
