Page 44
ECS-3M
RELATIVE HUMIDITY DISPLAY
This function displays the relative humidity
of the room.
Relative humidity is displayed in 1%
increments from a minimum display of 30%
to a maximum display of 90%. If a humidity
level lower than 30% is sensed, F2 is
displayed. On the other hand, if a humidity
level higher than 90% is sensed, Hi is
displayed.
Displaying the humidity level:
•
rotate the Selector dial to position (12),
•rapidly rotate the Adjuster dial back and
forth to enter secondary function mode.
The humidity level is displayed on the ECS.
RH
