Page 49
DESCRIPTION VALUE
INPUT POWER
− 12 AMP
−
115/230 -20%, +10% VAC
−
50 / 60 Hz
STAGE 1 (variable
speed)
− 6 AMP; inductive 115V / 230V
−
10 AMP; max (fuse 10A)
− Min. Rating 150mA at 115V*
− 300mA at 230V*
STAGE 2 (variable
speed)
−
6 AMP; inductive 115V / 230V
− 10 AMP; max (fuse 10A)
− Min. Rating 150mA at 115V*
−
300mA at 230V*
STAGE 3 (dry relay
contact)
Not Fused
− 10 AMP ; 115V/230V
−
1/2 HP @ 115V
−
1 HP @ 230V
− Min. Rating 10mA at 115V*
− 20mA at 230V*
ALARM (dry relay
contact)
− 2 AMP; 30V DC
SPECIFICATION
APPENDIX
* Relay will not function properly if load is smaller than
min. value.
