DEFINITION OF TERMS
DEFINITION OF TERMS
MAIN SET POINT
The desired room temperature. Other temperature
settings on the ECS-3M are relative to the main set
point temperature.
RELATIVE TEMPERATURE
A value added to, or subtracted from the main set
point, which results in a new temperature at which a
desired action starts or stops.
ROOM TEMPERATURE
The actual temperature in a closed area.
ROOM HUMIDITY
The actual humidity level of a closed area.
MINIMUM FAN SPEED
The desired minimum speed for variable speed fans.
RAMPING
An automatic daily reduction in the main set point and
all temperature settings relative to this.
DIFFERENTIAL
ON/OFF (relay). Range of temperature where two
conditions are possible. The output depends on
whether the temperature was increasing or decreasing
when it enters that range.
VARIABLE.
(Bandwidth) Temperature range where a
variable fan speed fan accelerates, as the
temperature increases. Minimum value at relative set
point and 100% at relative set point + Bandwidth.
