HIGH TEMPERATURE ALARM
This function establishes the temperature
difference above the main set point that
the room can reach before a high
temperature alarm is sounded. When a
high temperature alarm occurs, an alarm
contact is activated and the alarm LED
lights on the front panel.
The high temperature alarm is adjusted in
0.5 degree increments from a minimum
setting of 0°C (0°F) to a maximum setting
of 18.0°C (32.0°F)
Adjusting the high temperature alarm:
•rotate the Selector dial to position (12),
•
rapidly rotate the Adjuster dial back and
forth to enter secondary function mode,
•rotate the Selector dial to position (11),
•rotate the Adjuster dial counterclockwise
to decrease the setting, clockwise to
increase it.
The high temperature alarm setting is
displayed on the ECS.
.
Alarm
CHAPTER 3 - USER’S GUIDE
