VAT 613 Series - Errors

TROUBLE SHOOTING Series
613
122/149 Edition 12.08.2022 984360EC
7.2 Errors
If valve is in Control Mode Error, movement is no longer possible.
The following parameters provide information about the cause of the error:
Location: CPA/Parameters: System.Services
Parameter Description
Error Bitmap
Information about the types of errors. Details below.
Error Number
Information about the error component. Details below.
Also shown on the
controller
display when active
.
Error Code
Information about the different error states. Details below.
Also shown on the controller display when active.
If you need any further information, please contact one of our service centers.
You will find the addresses on our website: www.vatvalve.com
The following information is required for VAT to analyze the error case:
• Diagnostic File: CPA → Tools → Diagnostic File
• Load Error Data: CPA → Tools → Trace Log → Mode Load Error Data → Start
7.2.1 Error Recovery
To leave the error state, the Error Recovery or Restart Controller can be used:
Location: CPA/Parameters: System.Services
Parameter Description
Restart Controller
Emulates a power cycle of the valve
Error Recovery
Attempts to reset the Control Mode Error without restarting the valves
Create a diagnostic file before recovery or restart if the error is to be analyzed by VAT
7.2.2 Error Bitmap
Parameter Description
Error Bitmap
Bit Hex Description
0 1 Homing Position Error
1 2 Homing Not Running
2 4 Homing Error State
3 8 Operation Position Error
4 10 Operation Not Running
5 20 Operation Error State
12
1000
Other Component
30
40000000
General
31
80000000
Internal
