5.5.3 Power and Sensor supply concepts
This valve offers 3 alternative concepts to supply the sensor(s) with power. This depends on the sensor
type and valve version that is used.
Concepts:
24 VDC sensors:
• External +24 VDC supplied to POWER connector is feedthrough to SENSOR connector.
Refer to chapter «Power and sensor connection (+24 VDC sensors) ».
±
15 VDC sensors:
• External ±15 VDC supplied to POWER connector is feedthrough to SENSOR connector.
Refer to chapter «Power and sensor connection (±15 VDC sensors) without optional SPS
module».
• External +24 VDC supplied to POWER connector is converted into ± 15 VDC by the valve
internal SPS and supplied to SENSOR connector. Refer to chapter «Power and sensor
connection (±15 VDC sensors) with optional SPS module».
This concept is only possible when Sensor Power Supply (SPS) option is installed.
For max load consumption, refer to chapter «Technical Data – Control and actuating unit».
Valve versions:
• 61.. . - . . G . - . . . . / 61. . . - . . T . - . . . . / 61. . . - . . H . - . . . . SPS module not included
• 61. . . - . . A . - . . . . / 61. . . - . . C . - . . . . SPS module included
The SPS module can be retrofitted.
Refer to chapter Retrofit / replacement procedure for instruction.
