13.1.2 ISO-KF valve unit - aluminum blank, without heating
Item Description
Valve size
Product ordering number
DN 25 / 1”
61328 - KA . .
ISO-KF
DN 40 / 1½”
61332 - KA . .
ISO-KF
DN 50 / 2”
61334 - KA . .
ISO-KF
1 Spare parts kit valve unit 488956 485726 486738
2 Spare parts kit mechanical unit 488946 471287 471292
3 Spare parts kit valve body 240574 232271 232272
4 Spare parts kit plate 253255 232276 232277
Plate screws
361960
(2 pcs required)
353386
(2 pcs required)
353386
(2 pcs required)
13.1.3 ISO-KF valve unit – stainless steel, without heating
Item Description
Valve size
Product ordering number
DN 25 / 1”
61328 - KE . .
ISO-KF
DN 40 / 1½”
61332 - KE . .
ISO-KF
DN 50 / 2”
61334 - KE . .
ISO-KF
1 Spare parts kit valve unit 489057 486772 485723
2 Spare parts kit mechanical unit 488946 471287 471292
3 Spare parts kit valve body 342558 243089 237850
4 Spare parts kit plate 342563 243090 239549
Plate screws
361960
(2 pcs required)
353386
(2 pcs required)
353386
(2 pcs required)
13.1.4 Seals and grease
Item
Description
Valve size
Product ordering number
All sizes
613 . . - . . . .
5 Vacuum
seal kit
VITON ® 237235 (2x N-5100-204)
Others on request
Vacuum grease syringe 206792 (2ml), 206793 (5ml)
