8.2.2.2 Retrofit / replacement procedure
View on control and actuating unit:
All boards have a fixed position into control and actuating unit. It is not possible to fit a
board in other position as shown in picture above! Do not try out other positions,
which maybe destroy the socket of boards!
Master board
Option board
Interface board
