Series 613 INSTALLATION
984360EC Edition 12.08.2022 51/
149
5.12.7.1 System
Sub Group Parameter ID [hex] Data Type Acc NV Unit Min Max Description
Access Mode 0F0B0000 SINT8 RW V 0 2
0:Local
1:Remote
2:Remote Locked
Control Mode 0F020000 SINT8 RW V 0 14
0
:
Init
1:Homing
2:Position
3:Close
4:Open
5:Pressure Control
6:Hold
7:Learn
8:Interlock Open
9:Interlock Close 12:Power
Failure
13:Safety
14:Error
Identification
Serial Number 0F100100 STRING RO NV Identification of the product
Configuration
Valve Series 0F100201 UINT16 RO NV 0 670 Example: 655 means series 65.5 valve
Valve Variant 0F100202 UINT16 RO NV 0 100
Nominal Diameter 0F100203 UINT16 RO NV 0 62
20
:DN10
24:DN16
28:DN25
32:DN40
34:DN50
36:DN63
38:DN80
39
:DN88
40:DN100
44:DN160
46:DN200
48:DN250
50:DN320
51:DN350
52:DN400
54:DN500
56:DN630
58:DN800
60:DN1000
62:DN1250
Drive Parameters ID 0F10020B STRING RO NV Manufactory settings ID for motion
Configuration
Parameters ID
0F10020A STRING RO NV
Manufactory settings ID for
customer
-
accessible settings
:
Interface, Sensor, Pressure Control,…
Firmware
Valve Firmware ID 0F100301 STRING RO V
Valve Firmware
Version
0F100302 STRING RO V
CPA Version 0F100306 STRING RO V
Interface Firmware
Version
0F100303 STRING RO V
Motion Controller 1
Firmware Version
0F100304 STRING RO V Axis 1
Motion Controller 2
Firmware version
0F100305 STRING RO V Axis 2 → displayed if available
Motion Controller 3
Firmware version
0F100307 STRING RO V Axis 3
→
displayed if available
Motion Controller 4
Firmware version
0F100308 STRING RO V Axis 4 → displayed if available
Hardware
Controller Type 0F100401 UINT16 RO NV 1 5 1 … 7: IC2H1 … IC2H7
Interface Type 0F100402 UINT16 RO NV 1 8
1:RS232/485
2:EtherCAT
3:DeviceNet
5:Logic
7:Profibus
8:CC-Link
9: Ethernet
Option Type 0F100403 UINT16 RO V 0 15
0: Not Available
1: SPS
2: Cluster
3: SPS+Cluster
4: PFO
5: SPS+PFO
6: PFO+Cluster
7: SPS+PFO+Cluster
8: PFO2
9: SPS+PFO2
10: PFO2+Cluster
11: SPS+PFO2+Cluster
12: PFO3
13: SPS+PFO3
14: PFO3+Cluster
15: SPS+PFO3+Cluster
Statistics
Start Up Counter 0F200100 UINT32 RO NV
Total Time Powered 0F200200 UINT32 RO NV sec
Time Since Power On 0F200300 UINT32 RO V sec
Warning/
Error
Warning Bitmap 0F300100 UINT32 RO V Revere to Trouble shooting
Error Bitmap 0F300500 UINT32 RO V Revere to Trouble shooting
Error Number 0F300600 UINT16 RO V Revere to Trouble shooting
Error Code 0F300700 UINT16 RO V Revere to Trouble shooting
Services
Restart Controller 0F500100 BOOL RW V Emulates a power cycle
Error Recover 0F506600 BOOL RW V Attempts to fix the error without restart
Store /
Restore
Settings
Store User
Parameters
0F500202 BOOL RW V Back-up for all setting
Restore User
Parameters
0F500203 BOOL RW V Restore settings from the Back-up
Restore Factory
Parameters
0F500205 BOOL RW V Restores the delivery state
Configuration Lock
Mode
0F500500 BOOL RW NV
Locking the valve settings
.
If true, no changes to the
settings are possible.
0:not locked
1:locked
5.12.7.2 Valve
Sub Group Parameter ID [hex] Data Type Acc NV Unit Min Max Description
