VAT 613 Series

Series 613 INSTALLATION
984360EC Edition 12.08.2022 71/
149
5.12.8.4 Command Set Tylan
Command Specific Settings
Location: CPA\Parameters: Interface RS232/RS485.Settings
Parameter
Description
Tylan M1 Use of M command (Control Gain)
None
Gain Factor/P-Gain
Tylan X1 Use of X command (Control Lead)
None
Ramp Time/I-Gain
Tylan J1 Use of J command (Valve Type)
None
Restart
Commands
Note: Set commands have no response
Set
Get
Response
Description
Config
O Open
C
Close
H
Hold
Vx.x
Position Control with Target Position
Dn Setpoint Select
n Setpoint Nr 1..5
Snx.x
Rm
Snx.x
Setpoint Memory
n Setpoint Nr 1..5
m Setpoint Request Nr 1..4,10
Tnx Rm Tnx Setpoint Type
n Setpoint Nr 1..5
m Request Nr 26..30
0=Position, 1=Pressure
Mnx.x Rm Mnx.x Control Gain
n Setpoint Nr 1..5
m Request Nr 46..50
Tylan M1
Xnx.x
Rm
Xnx.x
Control Lead
n Setpoint Nr 1..5
m Request Nr 41..45
Tylan X1
Ax.x
Pressure Alignment with Target Value
Z Zero
Jx
R23
Jx
Valve Type
Tylan J3
R5
Px.x
Actual Pressure
R6 Vx.x Actual Position
R0
S0x.x
Analog Setpoint Value
1
R24
Ax
Analog Setpoint Range
0=5Volt, 1=10Volt
1
T0x R25 T0x Analog Setpoint Type
R7
Mxyz
Alternate System Status
x Value of Command X
y 0=Controlling, 2=Open, 4=Close
z 0=Pressure <= 10%SFS, 1=Pressure > 10%SFS
R8
C
Slipped (no effect)
R9
oclxs
OOCCLXXXS
R11
P10
Low Threshold process limit #1
1
R12 P20 High Threshold process limit #1 1
