5.12.8.6 Command Set Tylan Type 1
Command Specific Settings
Location: CPA\Parameters: Interface RS232/RS485.Settings
Parameter
Description
Tylan V Use of V command (Controller Selector)
None
Pressure Control Selector
Commands
Note: Set commands have no response
Set
Get
Response
Description
No Effect
O
Open
C
Close
H
Hold
Sx.x
R1
Pressure Control with Target Pressure
Px.x
Position Control with
Target Position
Z1 Zero Analog set point
Z2
Zero Pressure
A
Go to analog set point level and control
B
Reset the controller
D Same as A
Vx Control Mode (Controller Selector)
0=Adaptive, 1=PID
F1
Learn analog set point full scale
F2
Learn analog pressure full scale
Jx
R23
Jx
Valve Type
Tylan J3
Gx.x
R2
Gx.x
Control Gain
1
Lx.x R3 Lx.x Control Lead 1
R4
Analog set point
R5 Px.x Actual Pressure
R6
Vx.x
Actual Position
R8
Cx
Slipped
0=OK, 1=Slipped
R10 ZAx.x Pressure Alignment with Target Pressure
R11
ZB
Pressure Zero
R12
FA
Set point full scale
R13
FB
Pressure full scale
