Location: CPA/Navigation/Parameters: Pressure Sensor.Sensor 1, Pressure Sensor.Sensor 2
Parameter
Description
Available
Set to ‘True’ if a sensor is connected
Enable
Set to ‘True’ if the sensor signal is used for pressure
control
Input Source
‘
Analog’
‘Digital’
‘Simulation’
Sensor has an analog voltage interface
and is direct connected to the valve.
Sensor has an EtherCAT interface and is
connected to the EtherCAT bus
Testing the valve and pressure control
without being connected to the system
Range.Scale
Select type of the sensor signal
‘Linear’
‘Logarithmic’
Most gauges are linear type gauges.
Range.Data Unit
Set the pressure data unit of the gauge:
Pa, kPa, bar, mbar, Torr, mTorr, psia, psig
Range.Upper Limit Data Value
Range.Lower Limit Data Value
Set the upper limit and lower limit of the gauge in the unit
of “Range.Data Unit”
Example for a 250mTorr linear sensor:
Upper Limit = 250.0
Lower Limit = 0.0
Range.Upper Limit Voltage Value
Range.Lower Limit Voltage Value
These parameters are only used for gauges with analog
voltage interface.
The values corresponds to Range.Upper Limit Data Value
and Range Lower Limit Data Value
Example:
Upper Limit: 10.0V  250mTorr Range Upper Limit Data
Value
Lower Limit: 0.0V  0.0mTorr Range Lower Limit Data
Value
Filter.Enable
‘True’ enables the filter
Filter.Type
Set the filter type, which should be applied to the related
Sensor Input:
Low-pass, Low-
pass Simple, Median, Moving Average,
Line Frequency Suppression, FIR custom
Filter.Time
Set filter time in the range of 0.0 to 1.0 second.
Note: Filter delays the sensor signals which is detrimental
for pressure control
Value
The actual Pressure value of the regarding Sensor
