3. Before Installing the System
vatech A9 (Model: PHT-30CSS) Installation Manual 37
English
Part
No.
Items Specification Figure QTY
Comment
s
Confirmed
(OK?)
17 Base Cap White Silicon
4
Base
Option
Yes No
18 Terminal Cap White Silicon
2 Yes No
19 Left Blank Intentionally
20 Cable Tie
10 - Yes No
21
Cable Ethernet Cable
1 Yes No
Ethernet
Card
1 Yes No
22 Protractor
1 - Yes No
23 Wrench Bolt
M10 x 25
w/ Spring and
Flat Washer
4
Base
Option
Yes No
24 Wrench Bolt M8 x 20
2
Base
Option
Yes No
25
Wrench Bolt M8 x 35
4
Ceph
Option
Yes No
C_E_Washer
4
Ceph
Option
Yes No
26 Truss Bolt M4 x 6
13
Base
Option
Yes No
27
Pan Head
Screw
M4 x 6
11 Yes No
28
Ceph Cover -
1 Yes No
Washer
Head
Screw
M3 x 6
2 Yes No
29
Flat Head
Screw
M4 x 8
2 Yes No
30
Socket Set
Screw
M10 x 15
4
Floor
Mount
Yes No
