3. Before Installing the System
36 vatech A9 (Model:PHT-30CSS) Installation Manual
Part
No.
Items Specification Figure QTY Comments
Confirmed
(OK?)
7 Chinrest Special 1 Yes □ No □
8 Left Blank Intentionally
9 Chinrest Normal 1 Yes □ No □
10 Left Blank Intentionally
11
Sanitary Vinyl
Cover
For Normal Bite 1 Yes □ No □
12 Left Blank Intentionally
13 Left Blank Intentionally
14
Cap For Ear Rods 2
CEPH
Option
(2: on the
equipment)
Yes □ No □
Silicon Cover
For Nasal
Positioner
1
CEPH
Option: extra
Yes □ No □
15 Left Blank Intentionally
16 Silicon Cap White 15 Yes □ No □
17
Base Cap White Silicon 4 Base Option Yes □ No □
Terminal Cap White Silicon 2 Yes □ No □
18 Left Blank Intentionally
19 Truss Bolt M4 x16 4
For Vertical
Rear Cover
Yes □ No □
20 Cable Tie 10 - Yes □ No □
21 Cable
Power Cable - 1 - Yes □ No □
Ethernet Cable 1 Yes □ No □
