vatech A9 (Model: PHT-30CSS) Installation Manual 39
English
Part
No.
Items Specification Figure QTY Comments
Confirmed
(OK?)
Spring
Washer
M8 6 For Concrete Yes □ No □
Flat Washer M8 4 For Concrete Yes □ No □
Flat Anchor
Bolt
M8 x 30
4 For Concrete Yes □ No □
Hex Bolt M8 x 15 4 For Concrete Yes □ No □
