Vatech A9

3. Before Installing the System
40 vatech A9 (Model:PHT-30CSS) Installation Manual
Another location
Part
No.
Items Specification Figure QTY Comments
Confirmed
(OK?)
1
Base Top
Cover Rear
- 1 Yes □ No □
2
Base Top
Cover Front
- 1 Yes □ No □
3
Column Rear
Cover
1 Yes □ No □
4 Optical Module
CEPH
Option: extra
Yes □ No □
5
Column
Bracket
- 1 Yes □ No □
6 Wall Bracket - 1
For USA
only
Yes □ No □
7 Wall Bracket - 1
All countries
except the
USA
Yes □ No □
1
2
3
4
