Vathin DVM-D1 - Preparation and Operation

12
5
Video endoscope interface
(26-pin)
Insert the video endoscope cable here to connect the video
endoscope to the product.
6
Video endoscope interface
(14-pin for DVM-D1, 16-pin
for DVM-D2)
Insert the video endoscope cable here to connect the video
endoscope to the product.
7
HDMI interface
Connect an external high-definition monitor for display expansion
here.
8
Remote interface
Connect to a digital video recorder or digital filing system to
control the recording of images and videos
9
D-SUB9 interface
Connect to a digital video recorder digital filing system to control
the recording of images and videos
10
Stand 1
Supports the product on a plane surface or auxiliary handling.
11
SDI interface
Connect an external high-definition monitor for display expansion
here.
12
RJ45 interface
Connect the Local Area Network via network cable here.
13
Power socket
Receives 15 VDC input, and provides the power supply for the
entire system.
14
Stand 2
Supports the product on a plane surface or auxiliary handling.
5. Preparation and Operation
When using the product for the first time, please refer to this User Manual and install the product
according to the following steps.
Warning

Do not let the power cable become wet; otherwise, electric shock may be caused.

Do not prepare, inspect or use the product with wet hands.

Do not bend, pull or twist the power cable; otherwise, electric shock, equipment damage or fire
may be caused.

The product can be operated only according to the requirements given in "Operating
Environment", "Storage and Transportation Environment" of Chapter 9. Technical Specification;
Otherwise, malfunction, impaired safety and/or equipment damage may be caused.

Do not place any equipment on top of the product; otherwise, the product may be damaged.

Do not install the product near any strong electromagnetic radiation source (e.g. microwave
therapy equipment, shortwave therapy equipment, and MRI); otherwise, the product may
malfunction.

Before
each procedure, inspect the Digital Video Monitor as instructed below. Inspect other equipment
to be used with this Digital Video Monitor as instructed in their respective instruction manuals. If any
irregularity is observed, do not use the Digital Video Monitor.
