4
Contents .
CHAPTERS
8 Start up
8.1 Putting the basic machine into service 8 - 1
8.1.1 Switching on 8 - 1
8.1.2 Switching off 8 - 3
8.1.3 Emergency cut-out 8 - 4
8.1.4 Power failure 8 - 4
8.2 General Reset 8 - 4
9 Setting up basic machine
9.1 Preparation for Operation 9 – 1
9.1.1 Loading tape coil, feeding tape, setting guide height,
setting infeed top bar 9 – 1
9.1.2 End Trimming Band 9 – 5
9.1.3 Turning on the glue and setting height to match panel thickness 9 – 9
9.1.3.1 Setting glue height to match panel thickness 9 – 11
9.1.4 Setting glue start and stop adjustments 9 – 12
9.1.5 Setting Glue Pressures and Tape Presser 9 – 14
9.1.6 Setting the Nozzle Wiper 9 – 15
9.1.7 Loading a glue cartridge 9 – 16
9.1.7.1 Performing a glue-tape test 9 – 18
9.1.7.2 Manually purging glue cartridge 9 - 21
9.1.8 Selecting 360 degree setting for Butt Joint or Open Board 9 – 23
9.1.8.1 360 Degree Operation 9 – 24
9.1.8.2 Open Board Operation 9 – 27
9.2 Commencing a cycle 9 – 35
9.2.1 Setting Vacuum Cups and Lead Pods 9 – 35
9.2.2 Saving Start Positions 9 - 38
9.2.3 Single or Pendulum Operation 9 – 42
9.2.4 Start Cycle 9 – 43
9.2.4.1 Start Prevent Messages 9 – 44
9.2.5 Applying edging (without trimming or scraping) 9 – 45
9.2.6 Trimming edging (without gluing) 9 – 46
9.2.7 Setting trimmer shoes 9- 48
9.2.7.1 Setting horizontal trimmer tracer shoe 9 – 48
9.2.7.2 Setting vertical trimmer tracer shoe 9 – 50
9.2.8 Performing trimming and scraping cycle to test setup 9 - 53
9.2.8.1 Setting the glue joint scraper 9 – 54
9.3 Advanced Controls 9- 59
9.3.1 Advanced Controls: Glue 9- 60
9.3.2 Advanced Controls: Trimmer 9- 61
9.3.3 Advanced Controls: Scraper 9- 62
