Results
Magnetic interferences can
still lead to inaccurate
measurements, even if
compensation was
successful.
For this reason the compass
accuracy should be verified
after a successful
compensation by performing
several azimuth
measurements on known
landmarks and compare the
results.
After compensation, the
device acts on the
measurement results as
follows:
Acc (mil) Display Process
1-20 "Good"
"ACC xx"
The newly determined constants
are stored.
21-90 "bAdC"
"ACC xx"
The newly determined constants
are stored.
> 90 "bAdC"
"rESC"
The constants are reset to factory
values.
Possible causes of compen-
sation failures:
•movements were performed to
fast or jerkily
•the device was moved
while "StOP" was
displayed
L
If "bAdC" appears,
reattempt compensation
until "Good" is displayed.
Consider moving to an
alternative position.
