Veeder-Root EMR4 User Manual

Appendix A: EMR4 Setup - Programming Tips For Typical Single or Dual-head Installations with One IB
A-2
9 Meter Calibration (C&C - ref.
Figure 41 on page 44)
Normally you would select Autocalibrate. Note: Non-compensated prover
volume. Once calibrated, do proofs for yourself and W&M under normal
volume delivery mode. Toggle between compensated and non-compen
-
sated volume with arrow (+/-) keys on the EMR4 display. Compensated
volume has thermometer.
10 Configure I/O (C&C - ref.
Figure 45 on page 47)
• Emergency Stop
• Remote Start/Stop
• Printer Interlock
• Preset Interlock
• Transfer Interlock
• Remote Display and What
Master
Typical applications do not require these features. Turn on these features
only as needed.
11 OEM Message (C&C - ref.
Figure 46 on page 47)
This text message displays when the system is idle.
12 Delivery Options (C&C - ref.
Figure 47 on page 48)
• Price changing defaults to enable. Disable means that the delivery price
cannot be changed once a delivery has started.
• Delivery Timeout disable defeats the 3-minute time out. This feature
should not be disabled for normal truck deliveries, except for aviation
deliveries.
13 Report Formats - Delivery Ticket
(C&C - ref.
Figure 48 on page 50)
Line-by-line ticket format setup.
14 Printer Option - Set Advance
(Non-C&C ref.
Figure 17 on
page 21)
This is where you change the space between the top of the ticket and the
first printed line.
15 Security
• Security Code (C&C - ref.
Figure 51 on page 53).
• Security (Non-C&C ref.
Figure 16 on page 20)
• Enable, Disable, Reset Code. If Enable, security setup is then available.
The default is Disable.
• This setup is blocked if the Security Code (above) is disabled.
16 Start Screens Defaults (Non-
C&C Defaults/Start Modes, ref.
Figure 12 on page 16)
These are the Default Screens (Mode) Default is Volume mode.
17 Presets (Non-C&C Defaults/Pre-
sets, ref. Figure 13 on page 17)
Up to 3 volume (and 3 currency) presets are available for selection. Vol-
ume defaults are 100, 200, and 500, but you can change these.
18 Relay Control (Non-C&C, ref.
Figure 15 on page 19)
This is where the relays “volume to go” for 2-stage presets are adjusted.
Defaults are 5 and 0.1. You may want to change 5 to 3.
