Vapor Extraction Riser Kit w/o Coupling Adaptor
This kit contains parts needed to install a probe in a Vapor Extractor Riser that does not have a coupling adapter
(parts listed in Table 4 and shown in Figure 14):
Figure 14. Mag Probe Vapor Extractor w/o Coupling Adaptor Installation Kit
Table 4. Vapor Extraction Riser Kit (w/o coupling adaptor) - Part No. 846500-002
Quantity Description Part Number
2 Wire Nut 576008-461
1 Cable Tie 576008-482
1 Splice Enclosure 514100-357
1 Splice Kit Instructions Manual 576013-861
1 Riser Cap 331106-001
1 Gasket 331140-001
1 Cord Grip Bushing 330787-001
1 Cord Grip Nut 330594-001
12 inches Flex Conduit 576008-294
probes\nonvapr.eps
12 Inches Flexible Conduit
Splice Enclosure
4" NPT Riser Cap and Gasket
Cord Grip Bushing
Cord Grip Nut
Cable Tie
Wire Nuts
