Appendix B: Universal Sensor Mounting Kit Mounting Sensors
B-3
Figure B-3. Mounting the Sensor in the Dispenser Pan
sensors\mntsndp.eps
Sensor
Clamp
Extender
bracket
Support bar
3/8-16 Spring nut
3/8-16 x 7/8 hex bolt
1/4-20 x 3/4 hex bolt
w/ washer and nut
(not shown)
1/4-20 x 1-1/2
machine screw w/
washer and nut
