Appendix B: Universal Sensor Mounting Kit Mounting Sensors
B-5
Figure B-5. Mounting the Sensor to Rigid Conduit
U-Bolt
U-bolt
L-bracket
Clamp
Sensor
Rigid conduit
sensors\snlbkt.eps
1/4-20 x 3/4 hex bolt
w/ washer and nut
(not shown)
1/4-20 x 1-1/2
machine screw w/
washer and nut
