TLS Magnetostrictive Probes International Installation Guide Procedures for Installing Mag Probes
6
Figure 2. Procedures For Installing Mag Probes Using Wireless Connections
Mag Probe
Installation Complete
Install either a sleeve or an
adapter as shown on Figure 17,
then install the Mag Probe in a
riser pipe according to the
instructions on Figure 13 of this
manual.
Install a single channel surge
protector, part number 848100-
001, according to Figure 25 of
this manual.
Install the Mag Probe with a
process connection according to
the instructions on Figures 14 and
24 of this manual.
Riser PipeProcess Connection
Mag Probe
Installation Complete
Procedure for installing Mag
Probes into storage tanks
using a riser pipe.
NOTE: Use a riser pipe in
locations that do not require
bonding between the Mag
Probe and the tank structure.
Procedure for installing Mag
Probes into storage tanks
using a tube gland.
NOTE: Use a tube gland in
locations where it is
mandatory that the Mag Probe
be equipotentially bonded to
the tank structure.
