Figure 3. Mag Plus Probe Installation Kit 846402
Figure 4. Cable Seal Kit
031-11
Cable
Probe cable connector
(attaches to threaded connector
on the top of probe canister)
These two wires connect in the J-box or splice kit
to the two field wires from the console.
Product float
Product float
Water float (optional)
Sleeves
2-Inch Floats
Water float (optional)
1-Inch Floats
Adapters
Water float (optional)
Product float
3- or 4-Inch Floats
Note: your Mag Probe installation kit will contain
1-inch, 2-inch, 3-inch or 4-inch floats and either
adapters or sleeves as per your order.
Boot
To Next Page
