TLS Magnetostrictive Probes International Installation Guide Surge Protector
24
Figure 24. Example Wireless Installation With Process Connection And Single Channel Surge Protector
Figure 25. Example Wireless Installation With Riser Pipe And Single Channel Surge Protector
031-24.eps
Battery
Connection
Battery
Connection
Tie wrap cables
Transmitter
(far side of
bracket)
Battery pack
(this side of
battery support
bracket)
Cable from surge
protector
Red battery labels
two places
Single Channel
Surge Protector
S.P. Connection
Typical Detail
Bond 4 mm
2
wire
locally to tank
Pre-installed piping,
e.g., Dip Tube
Probe cable
Process connection (Gland)
Tank flange
W
B
W
B
Y/G
40mm
150mm
Battery
Connection
Battery
Connection
Tie wrap cable
Transmitter
(far side of
bracket)
Battery pack
(this side of
battery support
bracket)
Cable from surge
protector
Red battery labels
two places
Single Channel Surge Protector -
Install surge arrestor within 1m
of tank entry
S.P. Connection
Typical Detail
Bond 4 mm
2
wire
locally to tank
Riser
Tank flange
W
B
W
B
Y/G
Tie wrap cable
40mm
150mm
031-28.eps
