9 Diagnosis, asset management and service
VEGAPULS 63 • Modbus and Levelmaster protocol
41364-EN-170711
Code
Text message
Reason Rectication DevSpec
Diagnosis Bits
F265
Measurement func-
tion disturbed
•
Sensor no longer carries out a
measurement
•
Operating voltage too low
•
Check operating voltage
•
Carry out a reset
•
Disconnect operating voltage
briey
Bit 11
The following table shows the error codes and text messages in the
status message "Function check" and provides information on causes
as well as corrective measures.
Code
Text message
Reason Rectication DevSpec
State in CMD 48
C700
Simulation active
•
A simulation is active
•
Finish simulation
•
Wait for the automatic end after
60 mins.
"Simulation Active"
in"Standardized
Status 0"
The following table shows the error codes and text messages in the
status message "
Outofspecication" and provides information on
causes as well as corrective measures.
Code
Text message
Reason Rectication DevSpec
State in CMD 48
S600
Impermissible elec-
tronics temperature
•
Temperature of the electronics
inthenon-speciedrange
•
Check ambient temperature
•
Insulate electronics
•
Use instrument with higher
temperature range
Bit 5 of
Byte 14 … 24
S601
Overlling
•
Dangerofvesseloverlling
•
Make sure that there is no
furtherlling
•
Check level in the vessel
Bit 6 of
Byte 14 … 24
The following table shows the error codes and text messages in the
status message "Maintenance" and provides information on causes
as well as corrective measures.
Code
Text message
Reason Rectication DevSpec
State in CMD 48
M500
Error during the re-
set "delivery status"
•
The data could not be restored
during the reset to delivery
status
•
Repeat reset
•
LoadXMLlewithsensordata
into the sensor
Bit 0 of
Byte 14 … 24
M501
Error in the non-
active linearisation
table
•
Hardware error EEPROM
•
Exchanging the electronics
•
Send instrument for repair
Bit 1 of
Byte 14 … 24
M502
Error in the diag-
nostics memory
•
Hardware error EEPROM
•
Exchanging the electronics
•
Send instrument for repair
Bit 2 of
Byte 14 … 24
Function check
Outofspecication
Maintenance
