11 Supplement
VEGAPULS 63 • Modbus and Levelmaster protocol
41364-EN-170711
Ambient conditions
Ambient, storage and transport tempera-
ture
-40 … +80 °C (-40 … +176 °F)
Process conditions
Thefollowingspecicationsareforinformation.Thespecicationsonthetypeplatemustbenoted.
Process temperature
Antenna encapsulation Version Process temperature (measured on the process
tting)
PTFE and PTFE 8 mm Standard -40 … +200 °C (-40 … +392 °F)
Low temperature -196 … +200 °C (-321 … +392 °F)
TFM-PTFE and TFM-PT-
FE 8 mm
Standard -40 … +150 °C (-40 … +302 °F)
TFM-PTFE 8 mm Flange Alloy 400 (2.4360) -10 … +150 °C (14 … +302 °F)
PTFE Additional process seal,
FKM
-20 … +130 °C (-4 … +266 °F)
Additional process seal,
EPDM
-40 … +130 °C (-40 … +266 °F)
PFA and PFA 8 mm Standard -40 … +150 °C (14 … +302 °F)
High temperature -40 … +200 °C (-40 … +392 °F)
Vessel pressure
Version Processtting,pressure
stage
Vessel pressure
Standard (PTFE and PFA)
Flange PN 6 -1 … 6 bar (-100 … 600 kPa/-14.5 … 87 psig)
Flange PN 10 (150 lb) -1 … 10 bar (-100 … 1000 kPa/-14.5 … 145 psig)
Flange PN 16 (300 lb),
PN 40 (600 lb)
-1 … 16 bar (-100 … 1600 kPa/-14.5 … 232 psig)
Tieftemperature version up
to -196 °C (-321 °F)
Flange DN 50, DN 80
PN 16, PN 40
2", 3" 300 lb 600 lb
-1 … 20 bar (-100 … 2000 kPa/-14.5 … 290 psig)
Hygienic SMS -1 … 6 bar (-100 … 600 kPa/-14.5 … 87 psig)
Varivent
Clamp 3", 3½", 4" PN 10
PN 16
-1 … 10 bar (-100 … 1000 kPa/-14.5 … 145 psig)
Remaininghygienicttings -1 … 16 bar (-100 … 1600 kPa/-14.5 … 232 psig)
Vibration resistance 4gat5…200HzaccordingtoEN60068-2-6(vibration
with resonance)
Shock resistance
100 g, 6 ms according to EN 60068-2-27 (mechanical
shock)
