11 Supplement
VEGAPULS 63 • Modbus and Levelmaster protocol
41364-EN-170711
Electromechanical data - version IP 66/IP 67
Cable gland M20 x 1.5 or ½ NPT
Wire cross-section (spring-loaded terminals)
Ʋ Massive wire, stranded wire 0.2 … 2.5 mm² (AWG 24 … 14)
Ʋ Stranded wire with end sleeve 0.2 … 1.5 mm² (AWG 24 … 16)
Display and adjustment module
Display element Display with backlight
Measured value indication
Ʋ Number of digits 5
Ʋ Sizeofdigits W x H = 7 x 13 mm
Adjustment elements
Ʋ 4 keys [OK], [->], [+], [ESC]
Ʋ Switch BluetoothOn/O
Bluetooth interface
Ʋ Standard Bluetooth smart
Ʋ Eectiverange 25 m (82.02 ft)
Protection rating
Ʋ unassembled IP 20
Ʋ mounted in the housing without lid IP 40
Materials
Ʋ Housing ABS
Ʋ Inspection window Polyester foil
Functional safety SIL non-reactive
Interface to the external display and adjustment unit
Data transmission Digital (I²C-Bus)
Connection cable Four-wire
Sensor version Conguration,connectioncable
Cable length Standard cable Special cable Screened
4 … 20 mA/HART 50 m ● – –
ProbusPA,Founda-
tion Fieldbus
25 m – ● ●
Integrated clock
Date format Day.Month.Year
Time format
12 h/24 h
Timezone,factorysetting CET
Max. rate deviation
10.5 min/year
